Factory Supply/Quality guarranteed/Excellent service/
Fast delivery/Competitive price
1.Product Detail
Fast delivery/Competitive price
1.Product Detail
Grade | Br | Hcj | Hcb | (BH)max | (TW) | |||||
Mt | KGs | KOe | KA/m | KOe | KA/m | MGOe | Kj/m³ | ºC | ||
N | N35 | 1180-1210 | 11.7-12.1 | ≥12 | ≥955 | ≥10.9 | ≥868 | 33-36 | 263-287 | 80 |
N38 | 1210-1250 | 12.1-12.5 | ≥12 | ≥955 | ≥11.3 | ≥899 | 36-39 | 287-310 | 80 | |
N40 | 1250-1280 | 12.5-12.8 | ≥12 | ≥955 | ≥11.6 | ≥923 | 38-41 | 302-326 | 80 | |
N42 | 1280-1320 | 12.8-13.2 | ≥12 | ≥955 | ≥11.6 | ≥923 | 40-43 | 318-342 | 80 | |
N45 | 1320-1380 | 13.2-13.8 | ≥12 | ≥955 | ≥11.0 | ≥876 | 43-46 | 342-366 | 80 | |
N48 | 1380-1420 | 13.8-14.2 | ≥11 | ≥876 | ≥10.5 | ≥836 | 46-49 | 366-390 | 80 | |
N50 | 1400-1450 | 14.0-14.5 | ≥11 | ≥876 | ≥10.0 | ≥796 | 48-51 | 382-406 | 80 | |
N52 | 1420-1480 | 14.2-14.8 | ≥11 | ≥876 | ≥10.0 | ≥796 | 49-53 | 390-422 | 80 | |
M | 35M | 1170-1210 | 11.7-12.1 | ≥14 | ≥1114 | ≥10.9 | ≥868 | 33-36 | 263-287 | 100 |
38M | 1210-1250 | 12.1-12.5 | ≥14 | ≥1114 | ≥11.3 | ≥899 | 36-39 | 387-310 | 100 | |
40M | 1250-1280 | 12.5-12.8 | ≥14 | ≥1114 | ≥11.6 | ≥923 | 38-41 | 302-326 | 100 | |
42M | 1280-1320 | 12.8-13.2 | ≥14 | ≥1114 | ≥12.0 | ≥955 | 40-43 | 318-342 | 100 | |
45M | 1320-1380 | 13.2-13.8 | ≥14 | ≥1114 | ≥12.0 | ≥955 | 43-46 | 342-366 | 100 | |
48M | 1360-1430 | 13.6-14.3 | ≥14 | ≥1114 | ≥12.9 | ≥1027 | 46-49 | 366-390 | 100 | |
50M | 1380-1460 | 13.8-14.6 | ≥14 | ≥1114 | ≥12.9 | ≥1027 | 48-51 | 382-406 | 100 | |
H | 33H | 1130-1170 | 11.3-11.7 | ≥17 | ≥1353 | ≥10.5 | ≥836 | 31-34 | 247-271 | 120 |
35H | 1170-1210 | 11.7-12.1 | ≥17 | ≥1353 | ≥10.9 | ≥868 | 33-36 | 263-287 | 120 | |
38H | 1210-1250 | 12.1-1250 | ≥17 | ≥1353 | ≥11.3 | ≥899 | 36-39 | 287-310 | 120 | |
40H | 1250-1280 | 12.5-12.8 | ≥17 | ≥1353 | ≥11.6 | ≥923 | 38-41 | 302-326 | 120 | |
42H | 1280-1320 | 12.8-13.2 | ≥17 | ≥1353 | ≥12.0 | ≥955 | 40-43 | 318-342 | 120 | |
45H | 1320-1360 | 13.2-13.6 | ≥17 | ≥1360 | ≥12.5 | ≥955 | 43-46 | 342-366 | 120 | |
48H | 1350-1460 | 13.5-14.6 | ≥17 | ≥1360 | ≥12.5 | ≥955 | 46-49 | 366-390 | 120 | |
SH | 33SH | 1130-1170 | 11.3-11.7 | ≥20 | ≥1592 | ≥10.6 | ≥844 | 31-34 | 247-271 | 150 |
35SH | 1170-1210 | 11.7-12.1 | ≥20 | ≥1592 | ≥11 | ≥876 | 33-36 | 263-287 | 150 | |
38SH | 1210-1250 | 12.1-12.5 | ≥20 | ≥1592 | ≥11.4 | ≥907 | 36-39 | 287-310 | 150 | |
40SH | 1250-1280 | 12.5-12.8 | ≥20 | ≥1592 | ≥11.8 | ≥939 | 38-41 | 302-326 | 150 | |
42SH | 1280-1320 | 12.8-13.2 | ≥20 | ≥1600 | ≥11.8 | ≥939 | 39-43 | 310-342 | 150 | |
45SH | 1310-1360 | 13.1-13.6 | ≥20 | ≥1600 | ≥12.0 | ≥955 | 42-45 | 334-358 | 150 | |
UH | 30UH | 1080-1130 | 10.8-11.3 | ≥25 | ≥1900 | ≥10.2 | ≥812 | 28-31 | 223-247 | 180 |
33UH | 1130-1170 | 11.3-11.7 | ≥25 | ≥1900 | ≥10.7 | ≥852 | 31-34 | 247-271 | 180 | |
35UH | 1180-1220 | 11.8-12.2 | ≥25 | ≥1990 | ≥10.8 | ≥860 | 33-36 | 263-287 | 180 | |
38UH | 1210-1250 | 12.1-12.5 | ≥25 | ≥1990 | ≥10.6 | ≥844 | 36-39 | 287-310 | 180 | |
EH | 28EH | 1040-1090 | 10.4-10.9 | ≥30 | ≥2388 | ≥9.80 | ≥780 | 26-29 | 207-231 | 200 |
30EH | 1080-1130 | 10.8-11.3 | ≥30 | ≥2388 | ≥10.2 | ≥812 | 28-31 | 223-247 | 200 | |
33EH | 1130-1170 | 11.3-11.7 | ≥30 | ≥2400 | ≥10.5 | ≥835 | 31-34 | 247-271 | 200 | |
35EH | 1160-1200 | 11.6-12.0 | ≥30 | ≥2400 | ≥10.6 | ≥835 | 33-35 | 263-279 | 200 |
2.Coat
category | colour | Plating Thickness(UM) | Service temperature | Salt fog resistance | ||
NICUNI | silvery | 20-30 | ≤200ºC | >72hour | ||
NI | silvery | 10-30 | ≤2000ºC | >48hour | ||
ZN | Blue/color/silvery/black | 10-20 | ≤160ºC | >48hour | ||
Epoxy | black | 10-30 | ≤120ºC | >96hour | ||
Chemical nickel | silvery | 5-30 | ≤200ºC | >200hour |
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/506ece574e988fabf63c0bbc57ef7d97.webp)
3.Application
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/30dfa6918eadd6c1f85f0cad86e50469.webp)
4.Payment & Delivery
Payment Terms: 30% for deposit, 70% before shipment.(TT,Paypal L/C )
Package Details: Marine Packaging, Air Packaging, Vacuum Packaging and Neutral Packaging
Delivery:According to customer specifications and quantity budget delivery date, delivery can generally be 7-15 days.
Company Introduction
Zhejiang Meigot Import and Export Co., Ltd. is a professional exporter of Nd-Fe-B magnets. It has a special production and processing subsidiary company, Ningbo Yongpeng Magnetism Co., Ltd. Our company entered Nd-Fe-B industry in 2006. The scale of our company has gradually increased and the production and processing equipment is complete. We have a strong production capacity, and have first-class managers and technicians, can develop a variety of special-shaped magnets.
At present, we can produce magnets of various properties, such as: N. M. H, SH, UH, EH, all kinds of shapes can be produced according to the specific requirements of customers. Our products have a wide range of applications, such as: motor, toys, electronics, audio, mobile phones, computers, bags, generators and other industries.
All of our staff are looking forward to becoming business partners with your company, to give you the most reliable product quality, the most intimate production services.
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/c4ba2c5823d2e4a09361b9067531cf30.webp)
Factory Equipment
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/5f89e5e7dd8f926c9ed76dc4c7dfb7d7.webp)
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/9d16491e49d1b147d5cbcb0bb4ef18b4.webp)
Certification
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/af2980cb576257753016326af92601ac.webp)
Product show
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/b636aa36025d088238d9a509e66accfe.webp)
![45m Strong Magnets Round Disc Rare Earth Neodymium Magnets](https://img3.grofrom.com/magnethzxfco/08bd08edd5f87cc307706df7191b4a97.webp)
F&Q
1, What is information we need before quotation for NdfeB magnet?
Before our quotation, usually we need the following information.
The grade of Magnet and size and coating requirement.
2, What about the lead time for mass production?
Bulk lead time: 7-15 days according to the order quantity.
3, How long can I expect to get the sample?
After your payment of the sample charge and files confirmed , the samples will be ready for delivery in 3-5 days. The samples will be sent to you via express and arriving in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.
4, When can I get the price?
We usually quote within 24 hours. If you are very urgent to get the price, please call us (+86 13738887148) or tell us in your email , so we will regard your inquiry priority.
5, How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. If you just need a stock sample to check the quality, we will provide you sample for free, as long as you afford the express freight.
6, What is your terms of payment?
Normally 50% deposit, and 50% payment before shipment. Because all of magnets are custom made.
